Hotline Weatherproof Xov Tooj Nrog Lub Teeb JR101-CB-L
Raws li lub xov tooj kub xov tooj huab cua tsis zoo, nws muaj tag nrho nyob rau hauv ib qho kev tiv thaiv corrosion cam khwb cia txhuas weatherproof rooj nrog lub qhov rooj muab kev tiv thaiv tag nrho tiv thaiv plua plav thiab noo noo ingress, ua rau cov khoom lag luam txhim khu kev qha nrog MTBF ntev. Muaj rau Analog, SIP/VoIP, GSM/3G versions.Nrog rau tus xov tooj hu xovtooj, ib zaug tsa lub handset, nws yuav pib- hu rau tus xov tooj presaved rau hnub qub kev sib txuas lus.
Hauj lwm lawm
Tus Qauv Zauv: JR101-CB-L
Raws li ib tug weatherproof xov tooj, nws muaj tag nrho nyob rau hauv ib tug corrosion resistant cam khwb cia txhuas weatherproof rooj nrog ib lub qhov rooj muab kev tiv thaiv tag nrho cov plua plav thiab ya raws ingress, uas ua rau ib tug zoo txhim khu kev qha khoom nrog ib tug ntev MTBF.
Nrog rau txoj haujlwm kub xov tooj, ib zaug nqa lub xov tooj, nws yuav pib - hu rau tus xov tooj uas tau khaws cia rau hnub qub kev sib txuas lus.
APPLICATIONS of Hotline Weatherproof Xov tooj
Lub xov tooj weatherproof no nrov heev rauTunnels, Mining, Marine, Underground, Metro chaw nres tsheb, Railway platform, Txoj kev loj, Chaw ntiav pw, chaw nres tsheb, steel nroj tsuag, tshuaj nroj tsuag, fais fab nroj tsuag thiab lwm yam hnyav luag hauj lwm daim ntawv thov, thiab lwm yam.
TSEEM CEEB TSHAJ PLAWS ntawm Hotline Weatherproof Xov Tooj
- TxujAnaloguexov tooj los yogSIPxov tooj
- Aluminium alloy tuag-casting lub cev
- Vandal resistanthandset thiab armored cord
- Huab cua pov thawj tiv thaiv rauIP66-IP67
- Nrog LED teebtsau rau saum, nws yuav flashing thaum muaj kev hu tuaj
- Programmable rau hotline, ib zaug tsa lub handset, nws yuav pib - hu rau tus xov tooj presaved
- Phab ntsa / Pillar mounting, yooj yim installation
- Inductive coupler haum raws li tus qauv rau qhov tsis hnov lus
- Xov tooj kab powered (Analogue)
- Sab nraud fais fab mov lossis PoE (SIP)
- RJ45 Chaw nres nkoj rau SIP kev sib txuas
- Tau tshaj tus qauv SIP raws tu qauv, nws tus kheej nkag mus rau VOIP xov tooj system.
(Asterisk, Elastix, Grandstream, Cisco, Yeastar thiab lwm yam. IP mainstream -PBX)
- CE, FCC, IOS9001, RoHSua raws
TECHNICAL SPECIFICATIONS of Hotline Weatherproof Xov tooj
Analogue Version | |
Fais fab mov | Los ntawm analogue xov tooj network |
Cov khoom siv hluav taws xob | 24 VDC rau 65 VDC |
Cov khoom siv tam sim no | 20 mA DC rau 100 mA DC |
Ringer Volume | - 80dB(A) ntawm qhov deb ntawm 1 m |
Txoj kev hu xov tooj | DTMF hom raws li ITU-T pom zoo Q.23. |
Fais fab mov | PoE los yog 12V DC |
Kev siv fais fab | -Idle: 1.5W |
SIP Protocol | SIP 2.0 (RFC3261) |
Txhawb Codec | G.711 A/U, G.722 8000/16000, G.723, G.729 |
Hom kev sib txuas lus | Full duplex |
Ringer ntim | - 90~95dB(A) ntawm qhov deb ntawm 1 m |
Hom kev tiv thaiv | IP66 raws li EN60529 |
Ua haujlwm kub | -40degree rau +70 degree |
Cia kub | -45℃rau +85 degree |
CERTIFICATIONS
Cov yam ntxwv tseem ceeb ntawm Flashing Beacon
- Txais siv lub tshuab nqus tsev ua daim iav, Txhim kho qhov ci ntsa iab
- Rated kiv puag ncig:120-140 RPM
- Txais High Brightness LEDlub teeb ci ci, illuminance＞800 LX, Lub neej ntev＞1000teev
- Khoom siv:taws teeb-PSBase-ABS Reflector-ABS
- chav tiv thaiv:IP55
Specification ntawm Flashing Beacon
LED teeb lub teeb | |
Ua haujlwm voltage | DC 12 V,DC 24 V,DC 36 V,dc48v ua,AC 36 V,AC 48 V,AC 110V,AC 220 V,AC380V (yeem) |
Kev siv fais fab | 0.5W |
Cov av noo | 10% ~+ 90% |
Xim | Liab / Daj / Xiav / Ntsuab |
PACKAGE ntawm Hotline Weatherproof Xov Tooj
Qhov Loj: 339 * 246 * 126mm
Thawv loj: 200 * 300 * 440 (mm)
Cov khoom ntim: pearl paj rwb, thawv
Net nyhav: 6KG
Qhov hnyav tag nrho: 7 KG
Cim npe nrov: xov tooj hotline weatherproof xov tooj nrog lub teeb jr101-cb-l, weatherproof xov tooj, hnyav luag hauj lwm muaj xov tooj, humidity resistant xov tooj, IP67 sab nraum zoov pab taw tes, tshaj tawm xov tooj muaj, vandal-proof tunnel xov tooj, mining xov tooj, marine SIP xov tooj, tshuaj nroj tsuag Xov tooj, xov tooj kev lag luam, xov tooj cua tsis muaj hwj chim, xov tooj hu xov tooj, xov tooj hu xov tooj thaum muaj xwm ceev vandal resistant xov tooj, humidity resistant xov tooj, watertight industrial hu lub thawv
